How to Use a Fishbone Diagram: Solve Problems in the Factory

7 August 2025

A guide to problem-solving in the factory

Two manufacturers solving problems on the shop floor with a digital fishbone diagram (or Ishikawa) diagram on their ipad.

Production issues are an inevitable part of manufacturing, but recurring problems don’t have to be. Whether it’s a bottleneck in packaging or defects on the line, spotting the symptoms is only the first step. The real challenge lies in identifying the root cause and preventing it from happening again. That’s where the fishbone diagram, also known as the Ishikawa diagram or cause and effect diagram, is a great tool for your shop floor.

This simple yet powerful tool has long been a staple of lean manufacturing and continuous improvement strategies. In this blog post, we share how manufacturers can use the fishbone diagram to uncover hidden problems, strengthen quality problem solving, and ultimately drive better results on the factory floor.

What Is a Fishbone Diagram or Ishikawa Diagram?

The fishbone diagram is a visual tool used to systematically explore and display the potential causes of a specific problem. It gets its name from its shape: a central spine (representing the issue) with branches extending outward like bones, each representing categories of potential causes.

Also known as an Ishikawa diagram, or a cause and effect diagram, this tool breaks down complex problems into manageable elements. This makes it easier for teams to identify underlying issues rather than focusing solely on symptoms.

In the context of manufacturing operations, fishbone diagrams are especially help:

  • Identify causes of recurring production issues
  • Support root cause analysis in quality or safety investigations
  • Facilitate team-based problem solving sessions
  • Standardize approaches to issue resolution

When to Use a Fishbone Diagram in Manufacturing

The fishbone diagram is most effective when a manufacturing team is facing a well-defined problem, but isn’t sure what’s causing it. It’s a great tool to get to the root cause when an issue continues to recur.

Here are common scenarios where using a fishbone diagram delivers value:

  • Persistent Quality Defects: When similar defects keep appearing in a product batch or across shifts
  • Downtime Analysis: When machines frequently stop, but the reasons aren’t clearly known
  • Factory Safety Issues: When incidents occur under similar conditions but with unclear root causes
  • Supply Chain Disruptions: When late deliveries or material issues repeatedly impact production
  • Customer Complaints: When feedback points to recurring issues, but internal data isn’t conclusive

These kinds of recurring issues disrupt operations, and even more they come at a high cost. According to Deloitte, up to 68% of total quality costs stem from correction activities like rework, scrap, and warranty claims, while only 32% go toward prevention.

Structured tools like the fishbone diagram help guide teams to think logically and extensively about what could be causing the problem. The fishbone diagram organizes those causes into categories for easier, in-depth investigation.

Key Categories in a Fishbone Diagram: 6Ms of Manufacturing

To use a fishbone diagram effectively in manufacturing, it’s helpful to group causes into predefined categories. The most common framework is the 6Ms of Manufacturing, which includes:

  1. Manpower (People) refers to human factors such as operator error, lack of training, communication gaps, or insufficient staffing.
  2. Machine (Equipment) involves equipment failure, maintenance issues, outdated machinery, or improper tool usage.
  3. Material covers raw material defects, inconsistencies in suppliers, or incorrect materials being used.
  4. Method encompasses procedural flaws, outdated work instructions, or inconsistent processes.
  5. Measurement deals with inspection tools, calibration errors, or unreliable data collection methods.
  6. Mother Nature (Environment) includes environmental conditions such as temperature, humidity, lighting, or external disruptions.

These categories serve as the “bones” on the diagram’s main branches and help ensure a comprehensive approach to identifying all possible root causes.

Fishbone diagram, or Ishikawa diagram, graphic with 6Ms of manufacturing (Method, Manpower, measurement, machine, materials, Mother nature)
Illustration of the 6Ms in a Fishbone Diagram

How to Create a Fishbone Diagram Step-by-Step

Here’s a step-by-step guide to creating a fishbone diagram tailored for manufacturing teams:

Step 1: Define the Problem Clearly

Start by writing a concise, well-defined problem statement. Place this problem statement at the head of the fish. Make sure the issue is specific and observable. The clearer the definition, the better the diagram will guide your team’s analysis.

Step 2: Draw the Fishbone

Draw a long horizontal arrow pointing to the problem statement. This is your “spine.” From there, draw diagonal branches for each of the 6Ms. As described earlier, these categories help ensure you cover all angles of the problem, from equipment to human factors. Some teams find it helpful to color-code each category or use icons for visual clarity, especially in digital tools.

Step 3: Brainstorm Causes

Now it’s time to fill in the “bones”. With your team, brainstorm potential causes under each of the 6Ms. Encourage open participation and dig deep to reach root-level causes. Encourage open dialogue and avoid blaming individuals. This phase is about understanding the system, not assigning fault.

Step 4: Drill Down

For each cause, continue asking “why” to uncover deeper contributing factors. This iterative process often reveals unexpected insights. This is essentially combining the fishbone diagram with the 5 Whys technique, a lean manufacturing favorite.

Document each layer of questioning under the corresponding branch. This keeps the diagram structured and helps others follow the logic.

Step 5: Analyze and Prioritize

Once the diagram is complete, review each branch and circle the most likely root causes. Examine whether certain causes show up in multiple categories or if some branches are much fuller than others. You can do this through team voting, Pareto analysis (80/20 rule), or impact-effort scoring. Where available, validate assumptions with data such as downtime logs, quality inspection records, or operator checklists.

Step 6: Take Action

Translate insights into corrective actions. Document the changes, assign owners, and monitor the results to confirm the problem is resolved.

Don’t forget to measure impact over time. Use before-and-after data to confirm that your actions addressed the root cause and not just a symptom. Use the diagram as a “living document” to revisit and revise if new issues emerge.

Fishbone diagrams are meant to lead to quality problem solving that prevents recurrence. When used consistently, they promote a culture of continuous improvement. This enables manufacturers to move from reactive firefighting to proactive prevention. And when supported by digital tools, the fishbone diagram fuels data-driven decision-making, knowledge sharing, and faster problem resolution.

Going Beyond Paper: Why Digital Tools Matter

Fishbone or Ishikawa Diagram in fabriq. Example of the 6Ms in a digital tool with an example of a sensor not working in a machine.
Ishikawa Diagram (Fishbone Diagram) example in fabriq

Traditionally, fishbone diagrams are drawn on whiteboards or paper during team meetings. But as factories become more connected and data-driven, this approach has limitations:

  • No Easy Access: Paper diagrams can’t be referenced later without rework
  • Limited Collaboration: Remote or cross-shift teams can’t contribute easily
  • No Integration with Data: It’s hard to link causes to real-time KPIs or machine data
  • No Version History: Improvements aren’t tracked over time

Digital tools like fabriq solve these challenges by embedding lean manufacturing tools like fishbone diagrams into everyday operations. With a digital platform, teams can:

  • Create and update diagrams collaboratively, even across shifts or sites
  • Link root causes to specific metrics or incidents
  • Track progress and outcomes of corrective actions
  • Store knowledge for training and continuous improvement initiatives

When fishbone diagrams are integrated with live performance data and team workflows, they become a lever for continuous improvement. By using the fishbone diagram, manufacturers can move beyond guesswork and tackle the root causes of production issues with clarity and confidence.

Whether you’re trying to reduce defects or improve cycle time, fishbone diagrams support structured thinking. And when paired with digital tools like fabriq, they support a modern, scalable, and repeatable approach to operational excellence.
